SHANKS FOR BORING HEADS

SHANKS FOR BORING HEADS

SKU: 00184



Cat. no. Shank Draw Bar Mounting Thread Net Wt. Kgs.
CH184001 MT1 M6 M14 x 1 0.150
CH184002 MT2 3/8” - 16 7/8” x 20 0.300
CH184003 MT2 M10 7/8” x 20 0.300
CH184004 MT2 3/8” - 16 1.1/2” x 18 0.325
CH184005 MT2 M10 M14 x 1 0.300
CH184006 MT3 3/8” - 16 1.1/2” x 18 0.480
CH184007 MT3 M12 7/8” x 20 0.450
CH184008 MT3 M12 1.1/2” x 18 0.480
CH184009 MT3 M12 M14 x 1 0.450
CH184010 MT4 M12 1.1/2” x 18 0.650
CH184011 1/2” ST.   7/8” x 20 0.300
CH184012 5/8” ST.   7/8” x 20 0.340
CH184013 3/4” ST.   7/8” x 20 0.425
CH184014 1” ST.   1.1/2” x 18 0.550
CH184015 12mm ST.   7/8” x 20 0.300
CH184016 16mm ST.   7/8” x 20 0.340
CH184017 20mm ST.   7/8” x 20 0.425
CH184018 25mm ST.   1.1/2” x 18 0.550
CH184019 ISO 30 M12 1.1/2” x 18 0.600
CH184020 ISO 40 M16 1.1/2” x 18 1.000
CH184021 ISO50 M24 1.1/2” x 18 1.500
CH184022 BT 30 M12 1.1/2” x 18 1.325
CH184023 BT 40 M16 1.1/2” x 18 1.550
CH184024 BT50 M24 1.1/2” x 18 2.400
